Line Array Systems





DEL-123LA


The medium to large sized line array loudspeakers are used in applications including sound reinforcement for houses of Worship, Events, Indoor Stadiums, Theme Parks, Multi-Functional Auditoriums, Schools and Transit Terminals etc. Excellent for live, rental and portable sound reinforcement applications. The DEL Series Line Array loudspeakers deliver extraordinary performance where high speech intelligibility and natural sounding music is required at unmatched value.

  SPECIFICATIONS FEATURES



  Rated Power   600W (RMS)
  Construction   18mm Multilayered Plywood
  LF Driver   1 X 12", 3" VC,
  Ferrite Magnet
  HF Driver   1 X 1.4" Exit, 3" VC,
  Ferrite Magnet
  Crossover   Bi-amped Switchable to
  1.8kHz Passive
  Frequency Response (-3dB)   55Hz - 18kHz
  Maximum Peak Output   134 dB
  Rated Impedance   8Ω
  Dispersion (H X V)   100° X 15°
  Connector   2 X NL4R Speakon
  Packaging Dimensions
  L X B X H (cms)
  80 X 76 X 80 (2 pcs.)
  Net Weight   29 kgs
  Gross Weight   94 kgs (2 pcs)
  Biamped/ Passive System
  Large Scale, 2-way Line Array System
  Multiple Source Emulation
  Very High Output SPL & Sensitivity
   2 X NL4R Connector

APPLICATIONS

  Houses of Worship
  Rehearsal Halls
  Events
  Clubs
  Ballrooms
